材质:ZG200-400C
规格:80-20000kg
表面:黑漆
证书:CCS,ZC,BV,ABS,NK,LR,GL,RINA,KR,DNV
包装:裸装
名义重量 (KG) |
尺寸(mm) | 名义重量 (KG) |
尺寸(mm) | |||||||||||
A | B | C | D | E | H | A | B | C | D | E | H | |||
80 | 339 | 468 | 108 | 611 | 336 | 222 | 4050 | 1257 | 1732 | 400 | 2258 | 1244 | 821 | |
105 | 371 | 512 | 120 | 669 | 336 | 242 | 4320 | 1257 | 1732 | 422 | 2258 | 1244 | 831 | |
135 | 371 | 512 | 149 | 669 | 368 | 254 | 4590 | 1257 | 1732 | 444 | 2258 | 1244 | 841 | |
180 | 445 | 613 | 142 | 800 | 440 | 290 | 4890 | 1338 | 1846 | 426 | 2405 | 1325 | 874 | |
240 | 445 | 613 | 182 | 800 | 440 | 304 | 5250 | 1338 | 1846 | 450 | 2405 | 1325 | 888 | |
300 | 527 | 727 | 168 | 949 | 522 | 344 | 5610 | 1432 | 1974 | 431 | 2405 | 1418 | 936 | |
360 | 527 | 727 | 190 | 949 | 522 | 358 | 6000 | 1432 | 1974 | 457 | 2577 | 1418 | 936 | |
420 | 590 | 813 | 188 | 1062 | 584 | 385 | 6450 | 1432 | 1974 | 483 | 2577 | 1418 | 950 | |
480 | 590 | 813 | 211 | 1062 | 584 | 395 | 6900 | 1533 | 2112 | 462 | 2757 | 1518 | 1001 | |
570 | 652 | 900 | 208 | 1175 | 647 | 428 | 7350 | 1533 | 2112 | 488 | 2757 | 1518 | 1001 | |
660 | 653 | 900 | 236 | 1175 | 647 | 438 | 7800 | 1533 | 2112 | 514 | 2757 | 1518 | 1015 | |
780 | 725 | 1000 | 231 | 1305 | 718 | 473 | 8300 | 1621 | 2234 | 489 | 2916 | 1605 | 1059 | |
900 | 725 | 1000 | 264 | 1215 | 718 | 485 | 8700 | 1621 | 2234 | 517 | 2916 | 1605 | 1059 | |
1020 | 793 | 1093 | 252 | 1428 | 785 | 518 | 9300 | 1621 | 2234 | 545 | 2916 | 1605 | 1074 | |
1140 | 793 | 1093 | 277 | 1428 | 785 | 530 | 9900 | 1726 | 2380 | 520 | 3015 | 1709 | 1128 | |
1290 | 858 | 1183 | 273 | 1544 | 850 | 561 | 10500 | 1726 | 2380 | 550 | 3105 | 1709 | 1128 | |
1440 | 858 | 1183 | 299 | 1544 | 850 | 573 | 11100 | 1726 | 2380 | 580 | 3105 | 1709 | 1138 | |
1590 | 920 | 1268 | 293 | 1655 | 911 | 604 | 11700 | 1819 | 2507 | 554 | 3273 | 1801 | 1188 | |
1740 | 920 | 1268 | 315 | 1655 | 911 | 611 | 12300 | 1819 | 2507 | 580 | 3273 | 1801 | 1188 | |
1920 | 980 | 1350 | 312 | 1761 | 970 | 640 | 12900 | 1819 | 2507 | 607 | 3273 | 1801 | 1200 | |
2100 | 980 | 1350 | 337 | 1761 | 970 | 650 | 13500 | 1904 | 2624 | 577 | 3425 | 1885 | 1243 | |
2280 | 1038 | 1430 | 331 | 1866 | 1027 | 678 | 14100 | 1904 | 2624 | 607 | 3425 | 1885 | 1243 | |
2460 | 1038 | 1430 | 355 | 1866 | 1027 | 688 | 14700 | 1904 | 2624 | 650 | 3425 | 1885 | 1243 | |
2640 | 1090 | 1500 | 347 | 1959 | 1079 | 712 | 15400 | 1904 | 2624 | 657 | 3425 | 1885 | 1263 | |
2850 | 1190 | 1500 | 380 | 1950 | 1079 | 722 | 16100 | 2018 | 2782 | 612 | 3632 | 1998 | 1318 | |
3060 | 1144 | 1578 | 365 | 2058 | 1133 | 748 | 16900 | 2018 | 2782 | 638 | 3632 | 1998 | 1318 | |
3300 | 1144 | 1578 | 387 | 2058 | 1133 | 760 | 17800 | 2018 | 2782 | 683 | 3632 | 1998 | 1318 | |
3540 | 1202 | 1656 | 383 | 2159 | 1189 | 785 | 18800 | 2018 | 2782 | 699 | 3632 | 1998 | 1343 | |
3780 | 1202 | 1656 | 405 | 2159 | 1189 | 797 | 20000 | 2170 | 2990 | 652 | 3905 | 2148 | 1416 |
